Descriere
HARD DISK DRIVES:
INSTALLED HARD DRIVE: NONE.
UP TO FIFTEEN (15) 3.5-INCH SAS OR SATA HOT-PLUGGABLE HARD DISK DRIVES
DRIVE PERFORMANCE AND CAPACITIES:
15,000 RPM SAS DRIVES AVAILABLE IN 73GB, 146GB, 300GB, 450GB AND 600GB
10,000 RPM SAS DRIVES AVAILABLE IN 300GB, 400GB AND 600GB
NEARLINE SAS (7,200 RPM) DRIVES AVAILABLE IN 500GB, 750GB OR 1TB
7,200 RPM SATA II DRIVES AVAILABLE IN 250GB, 500GB, 750GB, 1TB AND 2TB
ENERGY EFFICIENT SATA II (5,400 RPM) DRIVES AVAILABLE IN 1TB AND 2TB
MAXIMUM CAPACITY PER ENCLOSURE:
1.1TB USING FIFTEEN (15) 73GB 15K SAS DISK DRIVES
MAXIMUM CAPACITY PER ENCLOSURE:
30TB USING FIFTEEN (15) 2TB DISK DRIVES
HOST CONNECTIVITY:
UNIFIED MODE: DIRECT CONNECTIVITY TO 15 DISK DRIVES AND BEYOND.
SPLIT MODE – DUAL HOST ACCESS:
CONNECTIVITY TO DRIVES 0 THOUGH 6 TO ONE HOST, A SEPARATE CONNECTIVITY TO DRIVES 7 THROUGH 14 TO THE SECOND HOST.
ENCLOSURE MANAGEMENT MODULES AND RAID LEVELS :
ENCLOSURE MANAGEMENT MODULES (EMMS):
1 OR 2 HOT-PLUGGABLE MANAGEMENT MODULES
RAID LEVELS:
PERC 6/E SUPPORTS RAID LEVELS 0, 1, 5, 6, 10, 50, 60 (INSTALLED)
PERC 5/E SUPPORTS RAID LEVELS 0, 1, 5, 10, 50
UP TO 30 PHYSICAL DISKS PER GROUP
UP TO 256 VIRTUAL DISKS
LED INDICATORS:
FRONT PANEL:
1 TWO-COLOR LED INDICATOR FOR SYSTEM STATUS
2 SINGLE-COLOR LED INDICATORS FOR POWER AND SPLIT MOD
HARD DRIVE CARRIER:
1 SINGLE-COLOR ACTIVITY LED
1 TWO-COLOR LED STATUS INDICATOR PER DRIVE
EMM:
3 TWO-COLOR LED STATUS INDICATORS: ONE FOR EACH OF THE EMM SAS PORTS AND ONE FOR THE EMM STATUS
POWER SUPPLY/COOLING FAN MODULE:
3 LED STATUS INDICATORS FOR POWER SUPPLY STATUS, POWER/SUPPLY/FAN FAULT AND AC STATUS
POWER SUPPLIES (PER SUPPLY):
INSTALLED POWER SUPPLY: 2X 478W (MAXIMUM CONTINUOUS), 550W (PEAK)
MAXIMUM HEAT DISSIPATION: 1430 BTU/HOUR (MAXIMUM)
INPUT VOLTAGE RANGE: 100-240V RATED (ACTUAL 90-26V)
FREQUENCY RANGE: 47-63HZ
AMPERAGE: 7.2A AT 100V, 3.6A AT 200V
DIMENSION & WEIGHT :
HEIGHT X WIDTH X DEPTH:
13.11 CM (5.16 INCHES) X 44.63 CM (17.57 INCHES) X 48.01CM (18.90 INCHES)
WEIGHT: 35.37 KM (78 LBS) (MAXIMUM CONFIGURATION)
